Duo Security Lab – Multi-factor Authentication for SSH

Part of a series of posts related to the cloud security company Duo Security, Inc. I am not affiliated in any way with Duo Security (please read my more extensive disclaimer below), I’m just doing my best to understand their offering.

Following the very clear instructions I found on https://duo.com/docs/duounix, I proceed to Duo my SSH. This is my topology:

I start by getting my Ubuntu 18.04 Server ready. Duo says we’ll be building from source and I need a compiler like GCC so I just installed the build-essential package. I also need libssl-dev and libpam-dev.

sudo apt-get install build-essential libssl-dev libpam-dev

Then I need to get the pam_duo source, untar and compile.

wget https://dl.duosecurity.com/duo_unix-latest.tar.gz
tar zxf duo_unix-latest.tar.gz
cd duo_unix-1.11.2
./configure --with-pam --prefix=/usr && make && sudo make install

The make program then spits out a bunch of gibberish that I will never understand, but I know it compiled ok because it didn’t say “error” a bunch of times. I’m very precise like that.

Next up I copy the keys and API hostname (the magic link to my Duo account) found when I click “Protect this application” on my Duo account under “applications”:

Then I put them in /etc/duo/pam_duo.conf file. It should look like this, according to the Duo documentation:

[duo]
; Duo integration key
ikey = DIGHFMF9NB25BEQJGHQZ
; Duo secret key
skey = NOTGONNATELLU
; Duo API hostname
host = api-b19c01d1.duosecurity.com

Then edit the pam sshd configuration file /etc/pam.d/sshd, find this line and comment it:

@include common-auth

Then add three lines so it looks like this:

auth  [success=1 default=ignore] /lib64/security/pam_duo.so
auth  requisite pam_deny.so
auth  required pam_permit.so

Lastly, restart the sshd daemon to apply the changes to sshd and duo.

sudo systemctl restart sshd

Once I get that all in place, I try SSHing (is that a word?) from the client to the server:

james@client:~$ ssh james@142.69.3.42
Please enroll at https://api-b19c01d1.duosecurity.com/portal?code=ca487343d044ab35&akey=DAVEM6A3YS7ML96IE4BJ
james@142.69.3.42's password:

I need to enroll my MFA device (my android phone) at https://api-b19c01d1.duosecurity.com/portal?code=ca487343d044ab35&akey=DAVEM6A3YS7ML96IE4BJ, so I head on over there and follow the prompts:

Then I try again SSHing from the client to the server. This time I get an MFA prompt on the command line:

james@client:~$ ssh james@142.69.3.42
Duo two-factor login for james

Enter a passcode or select one of the following options:

 1. Duo Push to XXX-XXX-7273
 2. Phone call to XXX-XXX-7273
 3. SMS passcodes to XXX-XXX-7273

Passcode or option (1-3): 1

Entering option 1 gets me a prompt from my Duo Push app on my phone to accept or deny the request (the app restricts taking a screenshot so I couldn’t include it, sorry), options 2 and 3 are pretty much what they look like.

Success. Logging you in...
Welcome to Ubuntu 18.04.2 LTS (GNU/Linux 4.15.0-20-generic x86_64)
Last login: Mon Jun 24 20:35:10 2019
james@server:~$

There is much rejoicing.
